BrightSign HD1025 is a digital signage player for 4K interactive signage that needs USB peripherals, serial control and GPIO in one BrightSign player. Choose the HD1025 when the screen needs the HD5 playback tier plus direct connections to a USB touchscreen, peripheral device or serial-controlled AV system.
What is BrightSign HD1025?
The BrightSign HD1025 is the expanded-I/O HD5 player for 4K digital signage and kiosk-style installations. It keeps the HD5 playback base of HDMI output, gigabit Ethernet, GPIO, IR and local microSD playback, then adds USB-A and a 3.5mm serial port for touchscreens, peripherals and installed AV control.
BrightSign HD1025 key features
- Single 4K HDMI playback for signage screens, kiosks and compatible processors that need a UHD source
- USB-A 2.0 for supported touchscreens and USB peripherals used in interactive signage
- 3.5mm serial port for integrations with displays, control systems and AV devices that use serial commands
- GPIO and IR for local triggers, button panels, LED indicators and basic installed-control events
- Gigabit Ethernet and local microSD playback for dependable publishing, scheduling and offline playback continuity
Where the BrightSign HD1025 makes sense
Touchscreen information kioskConnect a supported USB touch display and run interactive content without placing a Windows PC behind the screen.
Serial-controlled display installUse the serial port when the player needs to talk to a display, switcher or AV control path as part of the signage experience.
Button-driven exhibit or showroomCombine GPIO buttons with 4K playback so visitors can trigger product videos, room scenes or exhibit content from the player.
Interactive LED display sourceFeed a compatible processor or all-in-one controller while the BrightSign player handles local content, touch or control inputs upstream.
BrightSign HD1025 specifications
| Series |
HD5 |
| Product type |
Digital Signage Player |
| Price |
$600 |
Can the BrightSign HD1025 be used with an LED wall?
Yes, but its role is specific: the BrightSign HD1025 is the signage player that supplies the content signal. It stores and plays scheduled media, so a lobby screen, menu board or informational LED display does not need a computer left on-site just to keep content running.
For an LED wall, the BrightSign player’s HDMI output still needs to go into hardware that accepts and processes that signal. The NovaStar control system handles the LED-display work: a video processor or all-in-one controller accepts and scales the HDMI source, sending hardware outputs LED data, and receiving cards map that data to the LED modules. BrightSign handles the playlist, publishing method and playback reliability.
Stay with HD225 if GPIO is the only local trigger needed. Move to XD1035 when the installation needs PoE+, USB-C or more responsive multi-touch WebGL.
BrightSign HD5 model comparison
Start with output resolution and I/O. Those two choices usually decide the right BrightSign model faster than a long feature list.
| Model |
Best for |
Output tier |
I/O level |
Choose it when |
| HD225 |
Standard 4K signage |
Single 4K HDMI |
Standard I/O |
You need GPIO and gigabit Ethernet, but not USB or serial. |
| HD1025 |
Interactive 4K signage |
Single 4K HDMI |
Expanded I/O |
You need USB-A and serial for peripherals or control. |
BrightSign HD1025 datasheet and resources
BrightSign HD1025 datasheetOfficial BrightSign PDF for specs, interfaces and planning.Download datasheet
BrightSign HD1025 FAQ
Why choose BrightSign HD1025 instead of HD225?
Choose HD1025 when the player must connect to more than GPIO. HD225 is good for buttons and simple triggers; HD1025 adds USB-A and serial, which are often required for touchscreens, peripherals and installed AV control.
Can HD1025 be used with a touchscreen?
Yes, when the touchscreen and BrightSign presentation are built for supported USB touch interaction. HD1025 is the HD5 model to consider when the signage screen needs user input without moving to an XD or XT player.
What is the serial port on HD1025 used for?
The serial port is useful when the player needs to send or receive control commands with a compatible display, switcher, control processor or AV device. If the installation only needs HDMI playback and GPIO buttons, HD225 may be enough.
Does HD1025 support PoE+?
No. HD1025 uses the HD5 expanded-I/O package, but PoE+ belongs to the XD and XT tiers. If one-cable network power is important, compare XD235 or XD1035 instead.
Can HD1025 keep content running without a network connection?
Yes. Store the presentation on microSD and the current content can continue playing locally. Network access is mainly used for publishing updates, monitoring and managing the player.
Can HD1025 feed a NovaStar LED wall setup?
Yes, as an HDMI playback source into compatible processing hardware. HD1025 can manage the signage content and local interaction upstream, while the NovaStar controller, sending hardware and receiving cards handle the LED display path.
Is BrightSign HD1025 covered by a 5-year warranty?
New Series 5 players are eligible for BrightSign's registered 5-year hardware warranty program. Registration and BrightSign warranty terms apply; accessories, removable media and separately purchased items are handled separately.
Can I get reseller or bulk pricing for HD1025?
Yes. For kiosk projects, campus signage, retail networks or reseller stock, send the quantity, destination and installation timeline. We can quote HD1025 as a project or volume order instead of a one-off unit.
